R7F7010333AFP#KA4 Transistor Ic Chip Ic Mcu 32bit 1mb Flash 176lfqfp

Product Categories
SZ ADE Electronics Co., Ltd
Contact Now

R7F7010333AFP#KA4 Transistor Ic Chip Ic Mcu 32bit 1mb Flash 176lfqfp

Brand Name : original

Model Number : R7F7010333AFP#KA4

Certification : original

Place of Origin : original

MOQ : 1

Price : negotiation

Payment Terms : T/T

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Series : RH850/F1L

Package : Tray

Product Status : Active

Core Processor : RH850G3K

Core Size : 32-Bit Single-Core

Speed : 80MHz

Peripherals : DMA, PWM, WDT

Number of I/O : 150

Contact Now

R7F7010333AFP#KA4 Transistor Ic Chip Ic Mcu 32bit 1mb Flash 176lfqfp

RH850G3K RH850/F1L Microcontroller IC 32-Bit Single-Core 80MHz 1MB (1M x 8) FLASH 176-LFQFP (24x24)

Specifications of R7F7010333AFP#KA4

TYPE DESCRIPTION
Category Integrated Circuits (ICs)
Embedded
Microcontrollers
Mfr Renesas Electronics America Inc
Series RH850/F1L
Package Tray
Product Status Active
Core Processor RH850G3K
Core Size 32-Bit Single-Core
Speed 80MHz
Connectivity CANbus, CSI, I²C, LINbus, SPI, UART/USART
Peripherals DMA, PWM, WDT
Number of I/O 150
Program Memory Size 1MB (1M x 8)
Program Memory Type FLASH
EEPROM Size 32K x 8
RAM Size 128K x 8
Voltage - Supply (Vcc/Vdd) 3V ~ 5.5V
Data Converters A/D 28x10b, 32x12b
Oscillator Type Internal
Operating Temperature -40°C ~ 105°C (TA)
Mounting Type Surface Mount

Features of R7F7010333AFP#KA4

Unconnected CMOS device inputs can be cause of malfunction. If an input pin is unconnected, it is possible that an internal input level may be generated due to noise, etc., causing malfunction. CMOS devices behave differently than Bipolar or NMOS devices. Input levels of CMOS devices must be fixed high or low by using pull-up or pull-down circuitry. Each unused pin should be connected to power supply or GND via a resistor if there is a possibility that it will be an output pin. All handling related to unused pins must be judged separately for each device and according to related specifications governing the device.

Applications of R7F7010333AFP#KA4


Waveform distortion due to input noise or a reflected wave may cause malfunction. If the input of the CMOS device stays in the area between VIL (MAX) and VIH (MIN) due to noise, etc., the device may malfunction. Take care to prevent chattering noise from entering the device when the input level is fixed, and also in the transition period when the input level passes through the area between VIL (MAX) and VIH (MIN).

Environmental & Export Classifications of R7F7010333AFP#KA4

ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001

R7F7010333AFP#KA4 Transistor Ic Chip Ic Mcu 32bit 1mb Flash 176lfqfp


Wholesale R7F7010333AFP#KA4 Transistor Ic Chip Ic Mcu 32bit 1mb Flash 176lfqfp from china suppliers

R7F7010333AFP#KA4 Transistor Ic Chip Ic Mcu 32bit 1mb Flash 176lfqfp Images
