TLV5604ID Integrated Circuit Chip 10 Bit Digital To Analog Converter 4 16-SOIC

Product Categories
SZ ADE Electronics Co., Ltd
Contact Now

TLV5604ID Integrated Circuit Chip 10 Bit Digital To Analog Converter 4 16-SOIC

Brand Name : Original

Model Number : TLV5604ID

Certification : Original

Place of Origin : Original

MOQ : 1

Price : negotiation

Payment Terms : T/T

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Number of Circuits : 4

Settling Time : 18µs

Voltage - Supply, Digital : 2.7V ~ 3.3V, 5V

Output Type : Voltage - Buffered

Operating Temperature : -40°C ~ 85°C

Supplier Device Package : 16-SOIC

Contact Now

TLV5604ID Integrated Circuit Chip 10 Bit Digital To Analog Converter 4 16-SOIC

Features of TLV5604ID

Four 10-Bit D/A Converters
Programmable Settling Time
of 3 µs or 9 µs Typ
TMS320, (Q)SPI, and Microwire
Compatible Serial Interface
Internal Power-On Reset
Low Power Consumption:
5.5 mW, Slow Mode – 5-V Supply
3.3 mW, Slow Mode – 3-V Supply
Reference Input Buffers
Voltage Output Range ...2× the Reference

Product Attributes of TLV5604ID

TYPE
DESCRIPTION
Category
Mfr
T I
Series
-
Package Tube
Product Status
Active
Digi-Key Programmable
Not Verified
Number of Bits
10
Number of D/A Converters
4
Settling Time
18µs
Output Type
Voltage - Buffered
Differential Output
No
Data Interface
SPI
Reference Type
External
Voltage - Supply, Analog
2.7V ~ 3.3V, 5V
Voltage - Supply, Digital
2.7V ~ 3.3V, 5V
INL/DNL (LSB)
±1 (Max), ±0.1
Architecture
String DAC
Operating Temperature
-40°C ~ 85°C
Package / Case
16-SOIC (0.154", 3.90mm Width)
Supplier Device Package
16-SOIC
Mounting Type
Surface Mount
Base Product Number
TLV5604

Description of TLV5604ID


The TLV5604 is a quadruple 10-bit voltage output
digital-to-analog converter (DAC) with a flexible
4-wire serial interface. The 4-wire serial interface
allows glueless interface to TMS320, SPI, QSPI,
and Microwire serial ports. The TLV5604 is
programmed with a 16-bit serial word comprised
of word comprised of a DAC address, individual DAC control bits, and
a 10-bit DAC value.

Environmental & Export Classifications of TLV5604ID

ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001

TLV5604ID Integrated Circuit Chip 10 Bit Digital To Analog Converter 4 16-SOIC


Wholesale TLV5604ID Integrated Circuit Chip 10 Bit Digital To Analog Converter 4 16-SOIC from china suppliers

TLV5604ID Integrated Circuit Chip 10 Bit Digital To Analog Converter 4 16-SOIC Images
